Model	Primary DSP/CPU and (RAM)	CCD driver, CCD row driver, (CCD marking)	Power manager, PWM controller	Zoom driver, OIS driver, Mirror charge driver	IGBT	Audio/video controller, all other chips	System control processor, MCU	Battery	LCD	ZOOM	Comments
Canon 100D Also known as: Canon DS126441 Canon EOS 100D EOS Kiss X7 EOS Rebel SL1 Any other parts or stuff Canon 100D PCB Canon EF eyepiece Canon hotshoe	Digic CK4-1304 stacked	AD80282	ADP5035 0002	1013 AP1013EN	20AAJ CY20AAJ-8 - 130A 4V IGBT	30442 dust cleaner driver R2A30442NP 3700A 3700A 4717 BU97930 http://www.google.com/url?url=http://www.rohm.com/products/databook/driver/pdf/bu97930muv-e.pdf&rct=j&q=&esrc=s&sa=U&ei=g9J-VOLAEoiR7AaEyYDgDg&ved=0CCMQFjAD&usg=AFQjCNHNRTmkqnRIZsGhmu2nj6eBl3ND-w FM	F74966A	LP-E12	449AKM7 (1-886-583-11) touch	Canon 100D mirror box	Шторки подходят от 760D, при установке требуется рассверлить посадочное отверстие одного рычага, картоприемник высокий
Canon 5D mark IV Also known as: Canon 5D4 Any other parts or stuff Canon 5D mark IV PCB	Digic STACKED MB8AG1061 DH4-2665	AD80334	ADP5035 0004 MAX8972AEWI QWB	1013 AP1013EN 1013 AP1013EN		263 8452 MMA8452 3axis accelerometer 30442 dust cleaner driver R2A30442NP AKM 8142 MB8AA4701 R5f104CGA	F74966A F74966A	LP-E6N	A102987 touch	Canon 5D4 mirror box	Картоприемник низкий
Canon 5DSR Also known as: Canon DS126611 Any other parts or stuff Canon 5DSR PCB	Digic STACKED Digic STACKED Spartan-6 XC6SLX9	AD80282 AD80282 AD80282 AD80282	#523 LLM #523 LLM #523 LLM #529 LLM #529 LLM ADP5035 0004 ADP5035 0005 AK0 215 D60A0D	1013 AP1013EN 1013 AP1013EN		263 8452 MMA8452 3axis accelerometer 4957 ADV7524A BU9798 CH46313 D65499 LCMX02 4000HE PS3125 VHC157	F0535A F74966A F74966A		422AKM7 (1-882-500-11)	Canon 5DSR mirror box	Shutter looks exactly as 5D4, but P/N is different
Canon 6D Also known as: Canon DS126401 Any other parts or stuff Canon 6D battery cover Canon 6D LCD window Canon 6D PCB Canon EB eyepiece Canon hotshoe	Digic 5plus CH4-6501	AD80246	54326 54326 ADP5035 0002 D60A60D87	1013 AP1013EN 1013 AP1013EN		25L6436E 25Q32DWS1G 4646 4717 CH46313 D65499	F74965A	LP-E6	DX0860EBAA5 (1170 fl)	Canon 6D mirror box
Canon 6D mark II Also known as: Canon 6D mark 2 Canon 6D2 Canon DS126631 Any other parts or stuff Canon 6D mark II PCB Canon EB eyepiece	DSP STACKED	AD80334	1400 652C AP902A00 QUJ TPS63061	1013 AP1013EN 4851V 65497		13 7A 263 8452 MMA8452 3axis accelerometer 30442 dust cleaner driver R2A30442NP 4717 6314A AHC157 BU97981	F74965A R5F104C0A	LP-E6	A1008950S	Canon 6D mk 2 mirror box	Картоприемник высокий
Canon 750D Also known as: Canon DS126571 Canon EOS 750D Canon Rebel T6i Any other parts or stuff Canon 750D PCB Canon EF eyepiece Canon hotshoe Mini USB cable	Digic STACKED	AD80282	ADP5035 0002	1013 AP1013EN 1013 AP1013EN	TIG067	263 8452 MMA8452 3axis accelerometer 30442 dust cleaner driver R2A30442NP 4717 4958 63208 AHC157 BU97930 http://www.google.com/url?url=http://www.rohm.com/products/databook/driver/pdf/bu97930muv-e.pdf&rct=j&q=&esrc=s&sa=U&ei=g9J-VOLAEoiR7AaEyYDgDg&ved=0CCMQFjAD&usg=AFQjCNHNRTmkqnRIZsGhmu2nj6eBl3ND-w HC126 LCMX02 4000HE	F74965A	LP-E17	A1008950S touch	Canon 750D mirror box
Canon 760D Also known as: Canon DS126481 Canon EOS 760D Any other parts or stuff Canon 750D PCB Canon EF eyepiece Canon hotshoe Mini USB cable	Digic STACKED		ADP5035 0002	1013 AP1013EN 1013 AP1013EN	TIG067	263 8452 MMA8452 3axis accelerometer 30442 dust cleaner driver R2A30442NP 4717 4958 63208 AHC157 BU97930 http://www.google.com/url?url=http://www.rohm.com/products/databook/driver/pdf/bu97930muv-e.pdf&rct=j&q=&esrc=s&sa=U&ei=g9J-VOLAEoiR7AaEyYDgDg&ved=0CCMQFjAD&usg=AFQjCNHNRTmkqnRIZsGhmu2nj6eBl3ND-w HC126 LCMX02 4000HE	F74965A	LP-E17	A1008950S touch	Canon 750D mirror box

Model

Primary DSP/CPU and (RAM)

CCD driver, CCD row driver, (CCD marking)

Power manager, PWM controller

Zoom driver, OIS driver, Mirror charge driver

Flash charge driver

IGBT

Audio/video controller, all other chips

System control processor, MCU

Battery

LCD

ZOOM
