Model	Primary DSP/CPU and (RAM)	CCD driver, CCD row driver, (CCD marking)	Power manager, PWM controller	Zoom driver, OIS driver, Mirror charge driver	Audio/video controller, all other chips	System control processor, MCU	Battery	LCD	ZOOM	Comments
Sony A7 (2) Also known as: Sony A7 II Sony A7 mk II Sony A7m2 Sony ILCE-A7M2 Any other parts or stuff E-mount bayonet FDA EP-12 Eyepiece Sony A7 (2) PCB Sony SD MS combo reader	CXD90014GF STACKED	CXD90027GF	8072PN USB power management BD8331 Secondary RTC, HDMI power manager BD8336 OAP TI QUJ TPS63061 QUJ TPS63061	M02 US6M2 P+N MOSFET R2J30503	12904 NJM12904RB1 current monitor 263 8452 MMA8452 3axis accelerometer 403XX sot23-6 Backlight IC R1207N823B (403XX) BD11600N USB switch KM4924026 Type WN WiFi	MB9AF004	NP-FZ100	(ECX331C viewfinder) (LC-1024-11 lcd flex) 432BLQ1 (1-886-326-11)	Sony A7-3 shutter plate AFE-3360 AFE-3360 for A7M3, AFE-3313 for A7s	Мотор Sony A77 не подходит: упирается в гнездо наушников. Модуль взвода от A7III не подходит
Sony A7 (3) Also known as: Sony A7 III Sony A7 mk III Sony A7M3 Sony ILCE-A7M3 Any other parts or stuff E-mount bayonet FDA EP-12 Eyepiece Sony A7 (3) PCB Sony SD MS combo reader	CXD90045GG	(IMX410AQL) CXD90041GG	2G=4M 8072PN USB power management BD8336 QUJ TPS63061 QUJ TPS63061	R2J30503	112B 403XX sot23-6 Backlight IC R1207N823B (403XX) 4695 9950A NFC interface SS810609 Type 1DR WiFi VC125	MB9AF004	NP-FZ100	(ECX331D viewfinder) (LC-1039-11 lcd flex) 1540350820	Sony A7-3 shutter plate AFE-3360 AFE-3360 for A7M3, AFE-3313 for A7s
Sony A7R (2) Also known as: Sony A7R2 Sony A7RM2 Sony ICLE-7RM2 Any other parts or stuff E-mount bayonet FDA EP-12 Eyepiece Sony A7R (2) PCB Sony SD MS combo reader	(H5TC4G63CFR) CXD4236-1GG CXD90014GF STACKED	CXD90027GF	1200 56F 54326 8072PN USB power management BD8331 Secondary RTC, HDMI power manager BD8336 QUJ TPS63061 QUJ TPS63061	R2J30503	112B 12904 NJM12904RB1 current monitor 263 8452 MMA8452 3axis accelerometer 403XX sot23-6 Backlight IC R1207N823B (403XX) 4695 9950A NFC interface BD11600N USB switch KM5911312 Type WN WiFi	MB9AF004	NP-FW50	(ECX331C viewfinder) (FP500A viewfinder) (LC-1027-11 lcd flex) 432BLQ1 (1-886-326-11)	Sony A7s-2 shutter plate (AFE-3379) AFE-3379 for A7S2	Кнопка спуска угольная
Sony A7s (2) Also known as: Sony A7S2 Sony ILCE-7SM2 Any other parts or stuff E-mount bayonet FDA EP-12 Eyepiece Sony A7s (2) PCB Sony SD MS combo reader	CXD4236-1GG CXD90014GF STACKED	CXD90027GF	54326 8072PN USB power management BD8331 Secondary RTC, HDMI power manager BD8336 OAP TI QUJ TPS63061	4695 M02 US6M2 P+N MOSFET R2J30503	112B 263 8452 MMA8452 3axis accelerometer 403XX sot23-6 Backlight IC R1207N823B (403XX) 9950A NFC interface BD11600N USB switch Type WN WiFi	MB9AF004	NP-FW50	(LC-1027-11 lcd flex) 432BLQ1 (1-886-326-11)	Sony A7s-2 shutter plate (AFE-3379) AFE-3379 for A7S2
