Model	Primary DSP/CPU and (RAM)	CCD driver, CCD row driver, (CCD marking)	Power manager, PWM controller	Zoom driver, OIS driver, Mirror charge driver	Flash charge driver	IGBT	Audio/video controller, all other chips	System control processor, MCU	Battery	LCD	ZOOM	Comments
Acer CU-6530	LR38683	LR38675	BD9739KN	LB8659			4631	MB95107		TD025THEA1 (1891000032, 1701-91)	China Type 4 5.8-17.4mm	Короткий шлейф набок
Benq E610	ZR36463BGCG (8S)	AD9923	B1-8E B1-8K	LB8659						69.02A15.004	Casio Z40 5.8-17.4mm f
Casio Z110 Also known as: Casio EX-Z110	Casio R8J30224BG	(MN39830 6MP) AD9923	1331 A02A R128D002B BDR BDR	R2S30 401NP		25H8F	4631	11012	2xAA	Casio 1520 fl	Casio Z40 5.8-17.4mm f
Casio Z3 Also known as: Casio EX-Z3		3114Q AD80069	A15F A18F A33F	LB8649			4536		NP-20	Casio 2053M fl	Casio Z40 5.8-17.4mm f	Шлейф объектива отличается
Casio Z30	Casio R8J30204BG	AD9949 BGA OneC 520A	A02A R128D002B FA1 FA1	LB8659		25J8P	OKI L610501 WM8750			Casio 2064sh 2064M_fl	Casio Z40 5.8-17.4mm f
Casio Z4 Also known as: Casio EX-Z4	32934D4WG	AD9949A	A15F A18F A33F	LB8649		25AAJ	4630	L610501		Casio 2053M fl	Casio Z40 5.8-17.4mm f	Шлейф объектива отличается
Casio Z40	Casio R8J30204BG	AD9949 BGA OneC 520A	A02A R128D002B FA1 FA1	LB8659			OKI L610501 WM8750			Casio 2064sh 2064M_fl	Casio Z40 5.8-17.4mm f
Casio Z50	Casio R8J30204BG	AD9949 BGA	A02A R128D002B FA1 FA1	LB8659		25J8F	OKI L610501 WM8750		Casio NP-40	Casio 2064sh 2064M_fl	Casio Z40 5.8-17.4mm f
Casio Z55	Casio R8J30204BG	AD9948 Casio BAB4	A02A R128D002B FA1 FA1	LB8659			4631 OKI L610501			Casio 2804fl 2804sh	Casio Z40 5.8-17.4mm f
Casio Z57 Any other parts or stuff Casio Z57 PCB	Casio R8J30224BG	AD9923	BDR BDR	R2S30 401NP	BJW 4*4 SMD корпус, TPS65552A				Casio NP-40	Casio 2517fl	Casio Z40 5.8-17.4mm f
Ergo DC717	ZR36473BGCF (9S)	LR38678							2xAA	TD025THEE4 (304000025_A)	China Type 4 5.8-17.4mm
Ergo DC7375	ZR36473BGCF (9S)	LR38678	RT9911	R2S30 402NP	AN8K	P4002			2xAA	TD030WHEA1 (304000028_A) 304-08_A	China Type 4 5.8-17.4mm
Fujifilm F460	Sanyo SX8MVMU2464	AD9948 D3440 D3440	MAX8611	LB8659	APF	25H8P	H6412	533T uPD78F0533	NP-40	Casio 2556fl 2097-2sh	China Type 2 5.8-17.4mm
HP R742	Novatek NT96432BG	NN12069A	MAX8680	R2S30 402NP	LD7266	P4003				AUO 025DL02	China Type 4 5.8-17.4mm	дисплей подходит Samsung L700
Kodak C763	Altek AL87C0-2ABC	AD80157	RT9911	CAT5105CF	LD7267		LA74303		KLIC-7005		China Type 2 5.8-17.4mm	Шлейф объектива отличается, дисплей Nikon S200 под вопросом
Panasonic F1	103S5405	3114Q AD9895KBC	AN1149N	D169112K		25AAJ	12907 LV4141		S001E/BCA7	2CF4B10226 (127CLXG)	Panasonic F1 5.8-17.4mm 1:2.8-4.9
Panasonic FS1											Panasonic FX10 5.8-17.4mm 1:2.8-5.0	Шлейф объектива FS1 и FS10 разный
Panasonic FX10 Any other parts or stuff Panasonic FX10 PCB	MN103SE00	(MN39830 6MP) AD9923	BD9747KN	BUYD2202			U7615	BU7723		30632P00	Panasonic FX10 5.8-17.4mm 1:2.8-5.0
Panasonic FX12 Any other parts or stuff Panasonic FX10 PCB	MN103SE00	(MN39830 6MP) AD9923	BD9747KN	BUYD2202			U7615	BU7723		30632P00	Panasonic FX10 5.8-17.4mm 1:2.8-5.0
Panasonic FX7	103S790E	AD80076	BD9740KN	TB6554FLG		25J8F	LV4136	BU7225			Panasonic FX7 5.8-17.4mm 1:2.8-5.0
Panasonic LS2		(MN39623 5MP) 20101 AD9995	BD9745	BUYD2201		G022	BH76806	BU7225	2xAA	30422P00	Panasonic LS75 5.8-17.4mm 1:2.8-5.0	Объектив слегка отличается "ушами"
Panasonic LS3		AD9995				G022			2xAA		Panasonic LS75 5.8-17.4mm 1:2.8-5.0
Panasonic LS60	MN103SE00	AD9923	30216	BUYD2202		G022		BU7223	2xAA	30645P00	Panasonic LS75 5.8-17.4mm 1:2.8-5.0
Panasonic LS70	MN103SE00	AD9923	30216	BUYD2202		G022	BH76806	BU7223	2xAA	30645P00	Panasonic LS75 5.8-17.4mm 1:2.8-5.0
Panasonic LS75 Any other parts or stuff Panasonic LS75 PCB Panasonic LS75 service manual	MN103SE00	AD9923	30216	BUYD2202		G022	BH76806	BU7223		30646P00	Panasonic LS75 5.8-17.4mm 1:2.8-5.0
Pentax M10	Sanyo SX8MVMU2464	AD9949A D3443GA	NEC 168801	LB8659			WM8974G	F0532 uPD78F0532	2xAA	30404P00	China Type 2 5.8-17.4mm
Pentax S40 Also known as: Pentax Optio S40	ZR36442BGCF (6P)	NN12063A	MAX1566	LB8659		GT8G131			2xAA	Casio 1065sh B1048M fl	Casio Z40 5.8-17.4mm f	zoom flex differs
Pentax S5	Casio R8J30204BG	AD9949A	A15F A33F	LB8659		GT8G131			D-LI8	Casio 1516sh B1048M fl	Casio Z40 5.8-17.4mm f	шлейф объектива отличается
Pentax S55 Also known as: Pentax Optio S55	ZR36442BGCF (6P)	NN12063A	MAX1566	LB8659		GT8G131			2xAA	Casio 2092 fl	Casio Z40 5.8-17.4mm f	zoom flex differs
Polaroid I532	ZR36451BGCF (7M)	LR38667	AT1396AN	AT5555N	1454B = AT1454. All suffixes are equal	25H8F			2xAA	AUO 3AUT024B (642B100)	China Type 3 5.8-17.4mm 1:2.9-4.8
Polaroid I735	Sunplus SPCA5110A	(RJ23U3 7MP) AD9920A	AT1399AN	AT5558N	1454B = AT1454. All suffixes are equal					TD025THEEA , 025TUE006 (1891000130-GP, 304000129A)	China Type 2 5.8-17.4mm
Praktica 8303	Altek AL87C0-2ABC	AD80157	RT9911	CAT5105CF	LD7267					404000023 (404000396, 304-07_A)	China Type 2 5.8-17.4mm	Отличается шлейфом
Praktica DCZ 6.3	Sunplus SPCA537A	NN12067A	MAX1567	R2S30 401NP	LD7268	25AAJ			2xAA	LTV236WQ-F0B	China Type 3 5.8-17.4mm 1:2.9-4.8
Praktica DCZ 6.8	Sunplus SPCA5110A		AT1399AN	AT5558N		P4002				TD025THEEA , 025TUE006 (1891000130-GP, 304000129A)	China Type 2 5.8-17.4mm
Praktica DCZ 7.4											China Type 2 5.8-17.4mm
Praktica luxmedia 5203	ZR36451BGCF (7M)	LR38667	AT1396AN	AT5555N	1454B = AT1454. All suffixes are equal	25H8F			2xAA	AUO 3AUT024B (642B100)	China Type 3 5.8-17.4mm 1:2.9-4.8
Rekam 505 Also known as: Rekam iLook 505	Sunplus SPCA535A	20101 AD9943	MAX1566	BD6758		GT8G131	BA3308F		2xAA	Casio 2099f	China Type 3 5.8-17.4mm 1:2.9-4.8
Rekam SL65	ZR36463BGCG (8S)	NN12069A	AT1396AN AT1396AN	R2S30 401NP	1458ER	8G133			WGL-0101	Casio 2620fl	China Type 2 5.8-17.4mm
Rekam SLX8	Novatek NT96432BG	NN12092A	MAX8680	R2S30 402NP	LD7266					69.02A21.004	China Type 4 5.8-17.4mm
Rollei DS6	LR38683	LR38675		LB8659			4631	MB95107		TD025THEA1 (1891000032, 1701-91)	China Type 4 5.8-17.4mm
Samsung A40	ZR36441BGC (6M)	CXD3439GA	MAX1567	AT5555N							China Type 3 5.8-17.4mm 1:2.9-4.8
Samsung A400	Sunplus SPCA535A	20101 AD9943	MAX1566	BD6758	AT1453	GT8G131			2xAA	Casio 2053M fl	China Type 3 5.8-17.4mm 1:2.9-4.8
Samsung A50	ZR36451BGCF (7M)	D4802GA	AT1386AN							TC025THEA2 TC025THEA5	China Type 3 5.8-17.4mm 1:2.9-4.8
Samsung D60	ZR36463BGCG (8S)	LR36B11	MAX8611	BD6758					2xAA	69.02A17.010	China Type 2 5.8-17.4mm
Samsung D70 Any other parts or stuff Samsung D70 files	ZR36473BGCF (9S)	NN12069A	SN0509043 Маркировка чипа 59043A2	BD6758						LTV250QV-F0A	China Type 2 5.8-17.4mm
Samsung L60 Any other parts or stuff Samsung L60 PCB	ZR36460BGCG (8M)	AD9923	MAX1567	AT5556N	LD7268	25H8F			SLB-0837B	LTV236WQ-F0B	China Type 2 5.8-17.4mm	Шлейф объектива длиннее
Samsung L700	ZR36470BGCF (9M)	AD9923A	AT1399AN	AT5558N	1454B = AT1454. All suffixes are equal	P4002			SLB-0837 Отличается от SLB-0837B формой	69.02A27.002	China Type 2 5.8-17.4mm	Zoom flex diifers
Samsung L73 Any other parts or stuff SUC-C2 USB Cable	ZR36470BGCF	AD9923A	AT1399AN	AT5556N	1454B = AT1454. All suffixes are equal				SLB-0837B	69.02A27.001	China Type 2 5.8-17.4mm
Samsung S500 Also known as: Samsung D53	ZR36465BGCG (8M) Схема от l70	(C491 5MP) (RJ23S3 CAODT 5MP) D4805GA (CXD4805) i70 schematics LR38667	MAX8611	BD6758		8G133	BIQ		2xAA	LTV236WQ-F09	China Type 2 5.8-17.4mm	Разные ревизии плат, sharp (LR38667) и sony (D4805GA)
Samsung S600 Any other parts or stuff Samsung S600 files	ZR36465BGCG (8M) Схема от l70	(C624 6MP BIG) D4805GA (CXD4805) i70 schematics	MAX8611	BD6758					2xAA	LTV236WQ-F09	China Type 2 5.8-17.4mm
Samsung S630 rev. 1 Any other parts or stuff Samsung S630 rev. 1 PCB	ZR36463BGCG (8S)	LR36B11	MAX8611	BD6758		G022			2xAA	69.02A17.010	China Type 2 5.8-17.4mm	STS3-G3 SHARP(GL)V1.1
Samsung S630 rev. 2 Any other parts or stuff Samsung S630 rev. 2 PCB	ZR36463BGCG (8S)	(RJ23T3 6MP) LR36B11	MAX8611	BD6758		G022			2xAA	LMS250GF01	China Type 2 5.8-17.4mm	STS3 VE SEC
Samsung S700 Also known as: Samsung D73	ZR36463BGCG (8S)	NN12069A	MAX8611	BD6758		8G133			2xAA	69.02A17.008	China Type 2 5.8-17.4mm
Samsung S730 Any other parts or stuff Samsung S730 files	ZR36463BGCG (8S)	(MN39600 7MP) NN12069A	SN0509043 Маркировка чипа 59043A2	BD6758		G022			2xAA	LTV250QV-F0A	China Type 2 5.8-17.4mm
Samsung S750 Any other parts or stuff Samsung S750 PCB	ZR36463BGCG (8S)	(RJ23U3 7MP) LR36B11	MAX8611	BD6758		G022			2xAA	LMS250GF01	China Type 2 5.8-17.4mm
Sanyo E860 Also known as: Sanyo VPC-E860EX	Altek AL87C0-2ABC	AD80157		CAT5105CF	LD7267	P4002	LA74303		NP-40	404000023 (404000396, 304-07_A)	China Type 2 5.8-17.4mm
Sanyo S750	Altek AL87C0-2ABC	AD80157	AAT1415	AT5566AN	LD7260		LA74303		2xAA	TD024THEB8 Nikon L14 OK	China Type 2 5.8-17.4mm
Sanyo S760	Altek AL8700-2ABC	AD80157	AAT1415	AT5566AN		G030	LA74303			ACX392AKM-8	China Type 4 5.8-17.4mm
Sanyo S770	Altek AL87C0-2ABC	(RJ23U3 7MP) AD80157	AAT1415	AT5566AN	LD7260	G030	LA74303			TD024THEB8 Nikon L14 OK	China Type 2 5.8-17.4mm
Sanyo T700	Novatek NT96431CBG	LR38768	MAX8611	R2S30 402NP	LD7266		WM8974G		LI-42B	AUO 025DL02	China Type 4 5.8-17.4mm	дисплей подходит Samsung L700
Sony S650 Any other parts or stuff Sony S650 PCB	ZR36473BGCF (9S)	D4805GA (CXD4805) i70 schematics	MAX8680	AT5566N R2S30 402NP	LD7266	25J8F			2xAA	69.02A16.013 (02A15.018 shield)	China Type 4 5.8-17.4mm
Sony S700 Any other parts or stuff Sony S650 PCB	ZR36473BGCF (9S)	D4805GA (CXD4805) i70 schematics	MAX8680	R2S30 402NP	LD7266	25J8F				69.02A16.017 Совместим с Kodak C913 AUO (69.02A16.013)	China Type 4 5.8-17.4mm
Sony S730 Any other parts or stuff Sony S730 PCB	ZR36473BGCF (9S)	D4805GA (CXD4805) i70 schematics	AT1398AN	R2A30 420NP		25J8F			2xAA	69.02A16.017 Совместим с Kodak C913 AUO (69.02A16.013)	China Type 4 5.8-17.4mm	Объектив: шлейф как на картинке 4
Sony S750 Any other parts or stuff Sony S750 PCB	ZR36473BGCF (9S)	D4805GA (CXD4805) i70 schematics	RT9917	R2A30 420NP	LD7266	P4003			NP-BK1	ACX392AKM-8	China Type 4 5.8-17.4mm
Sony S780	ZR36473BGCF (9S)	AD9920A	MAX8857AE	R2A30 420NP						ACX392AKM-8	China Type 4 5.8-17.4mm	Шлейф объектива длинный, прямой. Не совместим с S650
Traveler XS7 Also known as: Traveler Suer Slim XS7	Novatek NT96431CBG	LR38768	MAX8611	R2S30 401NP	LD7266	25H8F	WM8974G			TD025THEA1 (1891000032, 1701-91)	China Type 4 5.8-17.4mm
Traveler XS80 Also known as: Traveler Suer Slim XS80	Novatek NT96432BG	NN12092A	MAX8680						LI-42B	69.02A21.004	China Type 4 5.8-17.4mm
UFO DC4320	Sunplus SPCA535A	20101 AD9943	MAX1566	BD6758		GT8G131				Casio 2053M fl	China Type 3 5.8-17.4mm 1:2.9-4.8
UFO DC5325 Also known as: UFO DC5327	Sunplus SPCA537A	NN12030A	MAX1567	R2S30 401NP	LD7260				2xAA	LTV236WQ-F0B	China Type 3 5.8-17.4mm 1:2.9-4.8
UFO DC6310 Any other parts or stuff UFO DC6310 PCB	ZR36463BGCG (8S)	NN12069A	AT1396AN AT1396AN	R2S30 401NP	1458ER					Casio 2620fl	China Type 2 5.8-17.4mm
UFO DC6320 Any other parts or stuff UFO DC6320 PCB	Sunplus SPCA537A	(MN39830 6MP) NN12067A	MAX1566	M50239	1458ER		WM8976G			Casio 2099f	China Type 3 5.8-17.4mm 1:2.9-4.8
UFO DC6325 Also known as: UFO DC6327	Sunplus SPCA537A	NN12067A	MAX1566	R2S30 401NP	LD7260				2xAA	LTV236WQ-F0B	China Type 3 5.8-17.4mm 1:2.9-4.8
UFO DC710	ZR36473BGCF (9S)	LR38678	RT9911	R2S30 401NP	AN8K				2xAA	TD025THEE4 (1701-256_V GP)	China Type 4 5.8-17.4mm
UFO DC717	ZR36463BGCG (8S)	LR38678	RT9911	R2S30 401NP							China Type 4 5.8-17.4mm
UFO DC718 Also known as: Ergo DC718	ZR36473BGCF (9S)	AD9923	AT1398AN	AT5556N	LD7260	8G133			2xAA	TD024THEB2 (304000012)	China Type 2 5.8-17.4mm
UFO DC7330 Also known as: Ergo DC7330 Ergo DS7330	ZR36463BGCG (8S)	NN12069A	AT1396AN AT1396AN	R2S30 401NP	1458ER	8G133			NP-40	Casio 3077fl 3068sh	China Type 2 5.8-17.4mm
UFO DM6331	LR38683	LR38675	BD9739KN	LB8659			4631	MB95107	Li-80B	TD025THEA1 (1891000032, 1701-91)	China Type 4 5.8-17.4mm
UFO DS700	ZR36463BGCG (8S)	NN12069A	AT1396AN AT1396AN	R2S30 401NP	1458ER	8G133			NP-40	Casio 2620fl	China Type 2 5.8-17.4mm
UFO DS7310 Also known as: Ergo DS7310	ZR36463BGCG (8S)	NN12069A	AT1396AN AT1396AN	R2S30 401NP	1458ER	8G133			NP-40	Casio 2620fl	China Type 2 5.8-17.4mm
